This special page shows all uploaded files.
| Date | Name | Thumbnail | Size | Description | Versions |
|---|---|---|---|---|---|
| 14:52, 6 August 2014 | Thermal mass refrigerator.png (file) |  |
8 KB | Schematic of Michael Reynolds' thermal mass refrigerator. The schematic was made based on a schematic found in the book "Earthship volume 3" by Michael Reynolds. A: insulated, gravity-operated skylight B: insulated, slide-out damper C: 4 inch rigid u... | 1 |
| 12:31, 6 August 2014 | Walk in cooler with thermal mass and outdoor cooling.png (file) |  |
19 KB | forgot to mention the door | 2 |
| 10:55, 6 August 2014 | Food dehydrator (hybrid).png (file) | .png) |
7 KB | Schematic of a food dehydrator designed by VDP, based mainly on [http://www.motherearthnews.com/real-food/preserving-food-homemade-dehydrator-zmaz75jazgoe.aspx?PageId=1 Peter Murphy's food dehydrator]. Peter's dehydrator was modified significantly by ... | 1 |
| 08:02, 4 August 2014 | Biodiesel reactor.JPG (file) |  |
242 KB | A schematic showing the design of a biodiesel reactor for making biodiesel from waste vegetable oil (WVO) or straight vegetable oil (SVO). The image was made based on an image in the book "Practical self-sufficiency by Dick and James Strawbridge" Prod... | 1 |
| 08:02, 4 August 2014 | Filtering WVO.png (file) |  |
14 KB | Schematic showing containers with WVO (ie obtained from restaurants) and a container with provisions to filter the waste vegetable oil (WVO). The provisions are: * a muslin (marked with "1") * a tap (marked with "4") The waste vegetable oil from the s... | 1 |
| 07:52, 4 August 2014 | HeatAndColdStorageWithHeatPump.png (file) |  |
45 KB | A picture of a heat pump system schematic combined with cold and heat storage, based on a schematic from Geotherm Energy systems. | 1 |
| 07:41, 4 August 2014 | OD natural house.JPG (file) |  |
326 KB | Sketch for a low-cost house design for disaster areas/refugee camps. The designed down shelter has been mainly inspired/based on the "straw bale temporary structure" mentioned in the Earthship Volume 3 book by Michael Reynolds (and also on the circular... | 1 |
| 12:53, 28 July 2014 | Intensive extensive green roofs.png (file) |  |
16 KB | Schematic showing the setup of an intensive and an extensive green roof. For the thicknesses of the growing medium layer of both, we can make a distinction into 4 types<ref>[http://www.conservationtechnology.com/documents/GreenRoofHandbook1008.pdf Dept... | 1 |
| 17:15, 23 July 2014 | Cabinet with desiccant dehumidifier.png (file) |  |
35 KB | Schematic of a cabinet with dessicant dehumidifier | 1 |
| 12:43, 15 November 2013 | Temp controlled seawater basin.JPG (file) |  |
384 KB | Schematic of a temperature controlled seawater basin. This design allows to grow/preserve coral species in secluded basins on the shore. As a huge number of coral species are in danger of becoming extinct in the next decades (especially in certain area... | 1 |
| 12:16, 1 October 2013 | Energy stacking in institutions.png (file) |  |
34 KB | schematic of energy stacking in SCN institutions | 1 |
| 12:15, 1 October 2013 | 2CN water use system.png (file) |  |
53 KB | Schematic of SCN water system | 1 |
| 12:15, 1 October 2013 | SCN semi-off grid system.png (file) |  |
267 KB | Schematic of SCN off-grid system | 1 |
| 12:10, 27 September 2013 | Heat recovery ventilation schematic.png (file) |  |
8 KB | Schematic of a heat recovery ventilation system in a house. *1: fresh air (from outside the house); can be either cold or hot; must atleast be o°C or above; at days this is not reached the air entering via this pipe must be heated, see [http://en.wik... | 1 |
| 12:07, 27 September 2013 | Counter current air to air heat exchanger.png (file) |  |
8 KB | Close up of the counter current air-to-air heat exchanger shown in Heat_recovery_ventilation_schematic.png The design was based on the images at http://www.southcoasttech.ca/fig1.gif and http://commons.wikimedia.org/wiki/File:Heat_exchanger.jpg *1: fr... | 1 |
| 10:45, 27 September 2013 | Heat pump system on rainwater pit.png (file) |  |
6 KB | Schematic of a heat pump system that uses a rainwater pit as a heat sink. The rainwater can be used at the house for showering (as indicated here), washing hands, flushing the flush toilets (if present), ... Note that the rainwater is herefore connecte... | 1 |
| 07:01, 3 August 2013 | Strawbridge heat sink.JPG (file) |  |
284 KB | Modified version of the Strawbridge heat sink for use in greenhouses, ... | 1 |
| 07:00, 3 August 2013 | CAESUS for vehicles.JPG (file) |  |
328 KB | A modified design of the Proe Ericsson cycle engine ( http://www.proepowersystems.com/ ) | 1 |
