This special page shows all uploaded files.
| Date | Name | Thumbnail | Size | Description | Versions |
|---|---|---|---|---|---|
| 18:01, 19 February 2011 | Liberator Foot 10in v2.2.PDF (file) |  |
33 KB | Example working drawing for the Liberator v2.2 Foot part | 1 |
| 04:37, 19 February 2011 | 20110218 Liberator v2.2 Frame WIP.PDF (file) | |
69 KB | My work-in-progress 3D PDF "snapshot" of the progress I've made in figuring out the frame of the Liberator v2 machine. | 1 |
| 04:22, 10 February 2011 | Liberator Master Part Model WIP 20110209.JPG (file) |  |
27 KB | cropped and resized | 2 |
| 19:43, 8 February 2011 | CEB V1.JPG (file) |  |
27 KB | A quick 3D rendering of the frame and compression chamber, based off the CEB v1 prototype documentation found at http://openfarmtech.org/weblog/wp-content/uploads/2007/12/ceb-v04.jpg to show I have some CAD skillz :) | 1 |
